Download area

Multi-page compilation of VKF approvals and technical information for fire protection products from RWD Schlatter AG (e.g. UNISTAR, ALLROUNDER, FLAMEX, SOUNDSTAR, CLEARSTAR, FORAS). Contains information on product designations, application areas (e.g. EI 30 / EI 60 / EI 90), test specifications (EN 1363-1, EN 1634-1, EN 1364-1, etc.), validity dates, system and EXAP references as well as information on direct and extended application areas. The first page of the document is used as an image on the website; the accompanying alt text is given in the "alternative" field.

Technical brochure on soundproof doors from Arbonia (RWD Schlatter). Contains chapter overviews and detailed pages on types of door frame (Pura, FlamEx, UniStar, SoundStar, Allrounder, ClearStar, Protect, ForasS), overview tables, laboratory values (Rw, C, Ctr), frame and seal details, glass cut-outs, frame extensions, measurement sheets, installation details and test reports. Intended for architects, planners and specialised trades; with contact and manufacturer details.

Product sheet for the "Allrounder 68" door leaf from Arbonia with fire protection. Door leaf with glued hardwood edge band, composite centre layer and hardboard top layer on both sides; suitable for special fire protection elements. Important characteristic values: Thickness approx. 67 mm, weight approx. 34 kg/m², sound Rw 37 dB, heat 1.1 W/m²K, fire EI30, smoke S200, burglary protection RC2. PEFC-certified, hardwood door moulding. Customised blanks up to a maximum of 3000 x 1500 mm (one-piece). Maximum EI30 sizes: 1-leaf 3500 x 3100 mm, 2-leaf 3500 x 5000 mm. Instructions and technical data sheets must be observed. (Status: 28/05/2025)

Product data sheet of the ARBONIA door leaf series Allrounder Alu 68 with fire protection (as of 28.05.2025). Contains brief description and technical characteristics: Thickness approx. 67.4 mm, weight approx. 37 kg/m², sound insulation Rw 37 dB, thermal transmittance 1.1 W/m²K, climate classes 3c/3d/3e, fire class EI30, smoke class S200, burglary protection RC2. Information on the structure (hardwood glued-in edge band, composite middle layer, aluminium sheet intermediate layer), maximum production sizes (mass blanks up to 2580×1380 mm; max. EI30 1-leaf 3500×3100 mm, 2-leaf 3500×5000 mm) as well as information on instructions and technical data sheets.

Product data sheet for the "Allrounder Alu RC 68" door leaf from ARBONIA (as of 28.05.2025). Fire-resistant door leaf with glued hardwood edge band, composite middle layer and exterior top layer on both sides with aluminium sheet intermediate layer. Important characteristic values: Thickness approx. 67.4 mm, weight approx. 37 kg/m², sound insulation Rw 37 dB, heat 1.1 W/m²K, climate 3c/3d/3e, fire EI30, smoke S200, burglary RC3. PEFC hardwood; dimension blanks up to 2580×1380 mm; maximum sash sizes for EI30 and RC3 are specified in the sheet.

Product data sheet for the UniStar Alu Top 58 door leaf version (with fire protection) from Arbonia. Contains product image, brief description and technical characteristics: Thickness approx. 57.4 mm, weight approx. 33 kg/m², sound insulation Rw 40 dB, heat 1.0 W/m²K, fire class EI30, smoke S200, burglary protection RC2. Information on areas of application (protected side entrance doors, unheated rooms), maximum sizes (single and double-leaf), information on PEFC/FSC (FSC on request) and reference to instructions and technical data sheets. Date: 28/05/2025.

Cover page of the Arbonia product sheet for the ClearStar 68 door leaf with fire protection. Includes brief description, information on designs on timber frames and steel frames, areas of application (private and public), VKF parameters (22602, 22604, 16426, 16428, 21549, 21550), examples of glazing options (fire-resistant glass EI30, soundproof glass) and references to instructions and technical data sheets. Date: 28/05/2025.

Product data sheet for the FlamEx 48 door leaf (as of 28/05/2025) from ARBONIA. Door leaf with fire protection (EI30) and solid chipboard centre layer, 7 mm hardboard top layer on both sides and finger-jointed hardwood edge band. Technical characteristics: 47 mm thick, approx. 33 kg/m², sound insulation Rw 34 dB, thermal transmittance 2.0 W/m²K, smoke class S200, burglary protection RC2. Suitable for office and basement doors; customised blanks up to max. 3000 x 1500 mm, maximum EI30 sizes: single-leaf 2640 x 1400 mm, double-leaf 2640 x 2300 mm. PEFC standard (FSC on request). Instructions and technical data sheets must be observed.

Product data sheet for the FlamEx 58 door leaf from Arbonia. Describes a fire protection door leaf with solid chipboard centre layer, hardboard cover layer on both sides (7 mm raw) and finger-jointed hardwood edge band; suitable for office and basement doors. Important characteristic values: Thickness 57 mm, weight approx. 39 kg/m², sound insulation Rw 34 dB, heat 1.7 W/m²K, fire EI30, smoke S200, burglary protection RC2. Information on maximum finished dimensions, PEFC standard (FSC on request) and reference to instructions and technical data sheets. Date: 28/05/2025.

First page of the product data sheet for the FlamEx Alu 48 door leaf from Arbonia. Describes a fire-resistant door leaf with solid chipboard centre layer, hardboard top layer on both sides, aluminium sheet intermediate layer and finger-jointed hardwood edge band. Important characteristic values: Thickness approx. 48.6 mm, weight approx. 36 kg/m², sound Rw 34 dB, heat 2.0 W/m²K, climate 2c, fire EI30, smoke S200, burglary protection RC2. Maximum sizes EI30: 1-leaf 2640×1400 mm, 2-leaf 2640×2300 mm. Notes: PEFC standard (FSC on request), observe instructions and technical data sheets. Date: 28/05/2025.

Product sheet for the FlamEx Alu 58 door leaf from ARBONIA with fire protection. Contains a cross-sectional illustration of the door core (solid chipboard centre layer, aluminium sheet intermediate layer, finger-jointed hardwood inserts) as well as technical parameters: thickness 58.6 mm, weight approx. 42 kg/m², sound Rw 34 dB, heat 1.7 W/m²K, climate 2c, fire EI30, smoke S200, burglary RC2. Further information on materials (hardwood, PEFC; FSC on request), maximum finished dimensions (customised blanks up to 2750×1450 mm in one piece; max. EI30: single leaf 3500×1660 mm, double leaf 3100×2640 mm) and intended use (suitable for heating and cellar doors or rooms with increased climate requirements). Date of issue: 28/05/2025.

Product data sheet for the FlamEx Top 48 door leaf from ARBONIA. Door leaf with solid chipboard centre layer, plywood reinforcement, 7 mm hardboard top layer on both sides and finger-jointed hardwood edge band. Suitable for office and cellar doors with slight temperature differences. Technical characteristics: Thickness 47 mm, weight approx. 33 kg/m², sound insulation Rw 34 dB, thermal transmittance 2.0 W/m²K, climate 2b, fire resistance EI30, smoke protection S200, burglary protection RC2. PEFC (standard), FSC on request. Maximum blanks up to 3000×1500 mm; Max. EI30 sizes: 1-leaf 2640×1400 mm, 2-leaf 2640×2300 mm. Document date: 28.05.2025. Notes: Observe instructions and technical data sheets.

Product sheet for the FlamEx Top 58 door leaf from Arbonia: Fire protection door leaf with solid chipboard centre layer and hardwood edge band. Technical characteristics: 57 mm thickness, approx. 39 kg/m², sound Rw 34 dB, heat 1.7 W/m²K, climate 2b, fire EI30, smoke S200, burglary RC2. Max. Finished dimensions, PEFC standard (FSC on request). Suitable for office and basement doors.

Cover page of the product sheet for the ForasS 68 door leaf from ARBONIA. Describes a fire-tested exterior door leaf with glued hardwood edge band, sound and thermal insulation centre layer and exterior hardboard top layer on both sides. Technical characteristics: Thickness 67.4 mm, weight approx. 41 kg/m², sound insulation Rw 45 dB, thermal transmittance 0.95 W/m²K, climate 3c/3d/3e, fire EI30, smoke S200, burglary protection RC3; PEFC standard, maximum blank sizes and information on permissible EI30/RC3 dimensions. Date: 28.05.2025. Note: Cut-outs in the sash only possible ex works.

First page of the technical data sheet for the Protect 48 door leaf (Arbonia). Contains product image of the untreated door leaf and main characteristics: Thickness 49 mm, weight approx. 62 kg/m², sound Rw 42 dB, heat 2.7 W/m²K, climate 3a/3b/3c, fire protection EI30, burglar resistance RC4. Material: Centre layer of highly compressed beech wood with hardboard covering on both sides; can only be installed in steel frames. Information on maximum finished dimensions (e.g. dimension blanks up to 2550 x 1400 mm, max. EI30 2640 x 1430 mm, Max. RC4 2310 x 1250 mm) and reference to instructions and technical data sheets to be observed. Date: 28/05/2025.

Product data sheet for the "Protect 68" door leaf from Arbonia. Sound-, fire-, burglary- and bullet-resistant door leaf with centre layer made of highly compressed beech wood and hardboard covering on both sides (untreated). Technical characteristics: thickness 67 mm, weight approx. 93 kg/m², sound insulation value Rw 42 dB, thermal transmittance 2.5 W/m²K, climate 3a/3b/3c, fire resistance EI30, burglary resistance RC4, bullet resistance class FB4. Dimension blanks up to a maximum of 2550 x 1400 mm (one-piece). Maximum dimensions: EI30 single-leaf 2640 x 1430 mm; RC4 single-leaf 2310 x 1250 mm. Note: Only possible on steel frame; instructions and technical data sheets must be observed. (Status: 28/05/2025)

Product sheet for the door leaf type Pura 40 from Arbonia. Hollow-core/tubular chipboard centre layer with hardboard top layer on both sides (3.5 mm raw) and MDF glued-in edge; thickness 40 mm, weight approx. 15 kg/m², sound Rw 32 dB, heat 1.9 W/m²K. Suitable for room, office and cellar doors. Customised blanks up to a maximum of 2685 x 1500 mm (one-piece). PEFC standard (FSC only on request), MinEco labelled. Notes: Observe instructions and technical data sheets; check fixings/drill holes in the centre position (e.g. double suspension).

Product data sheet for the Pura 40 CPL door leaf: Tubular chipboard centre layer with 3.1 mm CPL top layer on both sides, MDF edgeband. Technical characteristics: Thickness 39.2 mm, weight approx. 15 kg/m², sound Rw 32 dB, thermal transmittance 1.9 W/m²K. Suitable for room, office and basement doors; only available as an element in combination with a steel frame. Customised blanks up to a maximum of 2200 × 1000 mm. Notes on fixings, PEFC standard, date: 28/05/2025.

Product data sheet for door leaf type Pura 48 (without fire protection). Tubular chipboard centre layer with hardboard top layer on both sides (7 mm raw) and MDF lipping. Suitable for room, office and basement doors with complex constructions. Core data: Thickness 47 mm, weight approx. 22 kg/m², sound Rw 33 dB, heat 1.7 W/m²K. Customised blanks are produced up to max. 2685 x 1500 mm (one-piece). PEFC standard; FSC on request. Date: 28/05/2025.

Technical data sheet for the door leaf type PuraFlachs 40 (without fire protection) from Arbonia. Contains product description, structure with ecological fibreboard middle layer and hardboard top layer on both sides (3.5 mm), technical characteristics (40 mm thickness, approx. 20 kg/m², sound Rw 30 dB, heat 1.5 W/m²K), information on PEFC/FSC as well as dimensions (dimension blanks up to 3000 x 1500 mm) and installation/testing instructions. Date: 28/05/2025.

Product data sheet for the PuraLight 40 door leaf from Arbonia. Light chipboard centre layer with hardboard top layer on both sides (3.5 mm raw) and finger-jointed spruce liner; suitable for room, office and basement doors. Technical characteristics: Thickness 40 mm, approx. 22 kg/m², sound insulation value Rw 32 dB, heat 1.9 W/m²K, climate 2a. Dimension blanks up to a maximum of 3000 × 1500 mm (one-piece). PEFC standard (FSC on request). Note for glazing: Glass rod must be nailed and glued or screwed. Created: 28.05.2025.

Product data sheet for the Arbonia PuraPlus 40 door leaf series (without fire protection). Page with cross-sectional illustration and technical characteristics: Thickness 40 mm, weight approx. 26 kg/m², sound insulation Rw 33 dB, thermal transmittance 2.2 W/m²K. Construction: solid chipboard centre layer, hardboard top layer 3.5 mm on both sides, finger-jointed hardwood glued-in strips. Suitable for room, office and cellar doors; customised blanks up to 3000 × 1500 mm. PEFC standard, FSC on request. Date: 28/05/2025.

First page of the technical data sheet for the PuraPlus 40 CPL door leaf from ARBONIA. Includes product description and material structure (solid chipboard centre layer, 3.1 mm CPL top layer RWDS 9010/9016 on both sides, finger-jointed spruce lipping), key parameters (thickness 39.2 mm; weight approx. 26 kg/m²; sound insulation Rw 33 dB; heat 2.2 W/m²K), area of application (room, office and basement doors), note: only as an element in combination with a steel frame, as well as format information up to a maximum of 2200 x 1000 mm. Document date: 28/05/2025.

Product data sheet for the PuraFichte 40 door leaf from Arbonia (without fire protection). Describes a door leaf with tubular chipboard centre layer and hardboard top layer on both sides as well as finger-jointed spruce glued-in edge (top layer 3.5 mm raw). Suitable for room, office and cellar doors. Important characteristic values: Thickness 40 mm, weight approx. 15 kg/m², sound insulation Rw 32 dB, heat 1.9 W/m²K, climate 2a. PEFC standard, MinEco labelled, FSC on request. Note: Dimension blanks up to a maximum of 3000 x 1500 mm (one-piece); check fastenings/drill holes in the centre layer; observe instructions and technical data sheets.

Product data sheet for the door leaf type PuraFichte 48 (without fire protection) from Arbonia. Tubular chipboard centre layer with 7 mm hardboard top layer on both sides and finger-jointed spruce edge band. Technical characteristics: Thickness approx. 47 mm, weight approx. 22 kg/m², sound insulation Rw 33 dB, heat 1.7 W/m²K. Suitable for room, office and cellar doors; customised blanks up to a maximum of 3000 x 1500 mm (one-piece). PEFC standard (FSC on request). Date of manufacture: 28.05.2025. Fixings/drill holes in the centre layer must be checked before use.

Technical table of contents for ARBONIA doors (as of 28/05/2025). Multi-page product directory with an overview of the door types and series (e.g. Pura, FlamEx, UniStar, SoundStar, Protect, ClearStar, Allrounder, ForasS) as well as information on dimensions, structure, sound, fire and burglary protection classes, characteristic values and production information. Suitable for planners, architects and retailers.

Product data sheet for the SoundStar 40 door leaf from Arbonia. Door leaf with sound-insulating centre layer, hardboard top layer on both sides (3.5 mm raw) and finger-jointed spruce glued-in edge; suitable for high sound insulation requirements in offices, retirement homes, schools, hotels and upmarket residential areas. Characteristic values: 40 mm thickness, approx. 24 kg/m², Rw 43 dB, thermal transmittance 1.8 W/m²K; PEFC standard (FSC on request); customised blanks up to max. 3000 × 1500 mm; cut-outs only possible at the factory. (as of 28/05/2025)

Technical data sheet of the Arbonia door leaf type SoundStar 48 with fire protection. Describes the structure (sound-insulating centre layer, 7 mm hardboard top layer on both sides, finger-jointed hardwood edge band) and applications (offices, retirement homes, schools, hotels, sophisticated living). Contains characteristic values: thickness 47 mm, weight approx. 31 kg/m², sound insulation Rw 44 dB, thermal transmittance 1.6 W/m²K, fire EI30, smoke S200, burglary RC2; blasting: Lead 1-2 mm. Information on maximum sizes (mass blanks up to 3000×1500 mm; EI30: 1-leaf 2640×1400 mm, 2-leaf 2640×2300 mm), PEFC standard (FSC on request) and reference to installation instructions and technical data sheets.

Technical data sheet for the door leaf type SoundStar 58 with fire protection from ARBONIA. Contains characteristic values and product description: Thickness approx. 57 mm, weight approx. 36 kg/m², sound insulation Rw 45 dB, thermal transmittance 1.4 W/m²K, climate 2a, fire EI30, smoke S200, burglary protection RC2. Structure: Sound-insulating centre layer, 7 mm hardboard top layer on both sides and finger-jointed hardwood edging. Suitable for rooms with high sound requirements (offices, retirement homes, schools, hotels, sophisticated living). Notes: Dimensional blanks up to max. 3000 x 1500 mm (one-piece); Max. Size EI30: single leaf 3500 x 1660 mm, double leaf 3100 x 2640 mm; cut-outs only possible ex works; PEFC standard, FSC on request. Status: 28.05.2025. Instructions and technical data sheets must be observed.

Product data sheet for the SoundStar 68 door leaf with fire protection (as of 28/05/2025). Contains product description and technical characteristics: Thickness 67 mm, weight approx. 41 kg/m², sound insulation Rw 46 dB, thermal transmittance 1.2 W/m²K, fire EI30, smoke S200, burglary protection RC2. Information on structure (sound insulation centre layer, 7 mm hardboard top layer on both sides, finger-jointed hardwood edgeband), material information (PEFC / FSC on request), maximum finished sizes and information on cut-outs and technical data sheets.

Product data sheet for the SoundStar Alu Top 58 door leaf with fire protection. Technical characteristics: Thickness approx. 57.4 mm, weight approx. 39 kg/m², sound insulation Rw 45 dB, thermal transmittance 1.4 W/m²K, climate 3c/3d, fire EI30, smoke S200, burglary protection RC2. Structure: Sound-insulating middle layer, exterior top layer on both sides, aluminium sheet intermediate layer and finger-jointed hardwood inserts. Suitable for protected side entrance doors and unheated rooms. Max. Blank dimensions up to 2580×1380 mm (one-piece); maximum EI30 sizes single-leaf 3500×1660 mm, double-leaf 3100×2640 mm. Information on PEFC/FSC, application and technical data sheets must be observed. Date: 28/05/2025.

First page of the technical data sheet from Arbonia for the SoundStar Alu 48 door leaf with fire protection. Contains product image (cross-section), logo and a table with characteristic values: thickness 48.6 mm, weight approx. 34 kg/m², sound insulation Rw 44 dB, heat 1.6 W/m²K, climate 2c, fire EI30, smoke S200, burglary RC2. Information on materials (hardwood, aluminium sheet interlayer), production sizes (max. blanks up to 2750 x 1450 mm; max. EI30: 1-leaf 2640 x 1400 mm, 2-leaf 2640 x 2300 mm), information on PEFC/FSC and factory cuts as well as intended use (high sound and climate requirements in offices, retirement homes, schools, hotels). Date specification: 28/05/2025.

Product data sheet from Arbonia for the SoundStar Alu 58 door leaf with sound-insulating middle layer, hardboard top layer on both sides, aluminium sheet intermediate layer and finger-jointed hardwood inserts. Used for rooms with high sound and climate requirements (offices, schools, hotels, retirement homes). Key parameters: thickness approx. 58.6 mm; weight 39 kg/m²; sound insulation Rw 45 dB; heat 1.4 W/m²K; climate 3c; fire EI30; smoke S200; burglary protection RC2. PEFC standard, FSC on request. Information on maximum formats, cut-outs and processing instructions can be found in the data sheet.

First page of the technical data sheet for the SoundStar Alu 68 door leaf from Arbonia. Door leaf with sound-insulating middle layer, hardboard top layer on both sides and aluminium sheet intermediate layer, with finger-jointed hardwood inserts. Used for high sound and climate requirements (e.g. offices, retirement homes, schools, hotels, sophisticated living). Important characteristic values: Thickness approx. 68.6 mm, weight 45 kg/m², sound insulation Rw 46 dB, heat 1.2 W/m²K, climate 3c, fire EI30, smoke S200, burglary RC2. Production up to max. 2750 × 1450 mm (one-piece); maximum EI30 sizes: 1-leaf 3500 × 2100 mm, 2-leaf 3500 × 2640 mm. Notes: Cut-outs only possible ex works, bulges may occur depending on the surface. Date: 28/05/2025.

First page of the product data sheet for the ARBONIA door leaf type "SoundStar Alu RC 58" with fire protection. Contains a brief product description (sound insulation middle layer, hardboard on both sides with aluminium sheet interlayer, unfinished, finger-jointed hardwood inserts), recommended areas of application (offices, retirement homes, schools, hotels, sophisticated living) and technical parameters: thickness approx. 57.8 mm, weight approx. 43 kg/m², sound insulation Rw 45 dB, heat 1.4 W/m²K, climate 3c, fire EI30, smoke S200, burglary protection RC3. Information on maximum finished dimensions (EI30 and RC3), reference to PEFC standard (FSC on request) and date 28.05.2025. Also contains a product image of the door structure and information on manufacturing and processing conditions.

First page of the technical data sheet for the "SoundStar Alu RC 68" door leaf from Arbonia. Contains product description (sound-insulating middle layer, aluminium sheet intermediate layer, hardwood liner, fire protection), important characteristic values (thickness 68.6 mm, weight 45 kg/m², sound insulation Rw 46 dB, heat 1.2 W/m²K, climate 3c, fire EI30, smoke S200, burglary RC3), information on maximum door sizes (EI30/RC3), typical areas of application as well as information on PEFC/FSC and manufacturer's instructions. Date: 28/05/2025.

Product sheet for the UniStar 40 door leaf with fire protection (EI30). Door leaf 40 mm, approx. 19 kg/m², sound insulation Rw 39 dB, heat 1.3 W/m²K, climate 2a. Construction: sound-insulating centre layer, hardboard top layer 3.5 mm on both sides, finger-jointed hardwood edge band. PEFC standard (FSC on request). Customised blanks up to a maximum of 3000 × 1500 mm; maximum EI30 size single-leaf 900 × 2100 mm. Suitable for room closures with increased sound requirements (offices, retirement homes, schools, hotels). Cut-outs only ex works; instructions and technical data sheets must be observed. Manufacturer: Arbonia, as at 28/05/2025.

First page of the technical data sheet for the ARBONIA UniStar 48 door leaf series with fire protection. Brief description of the product: Door leaf with sound-insulating centre layer and hardboard top layer on both sides, hardwood edge band. Important characteristic values: 47 mm thickness, approx. 26 kg/m², sound insulation Rw 40 dB, heat 1.2 W/m²K, climate 2a, fire EI30, smoke S200, burglary RC2. Note on material/standards: PEFC (standard), MinEco, customised blanks up to max. 3000 x 1500 mm; Max. Size EI30: 1-leaf 2640 x 1400 mm, 2-leaf 2640 x 2300 mm. Instructions and technical data sheets must be observed.

First page of the product sheet for the UniStar 58 door leaf from ARBONIA. Contains logo, product name, image/graphic of the door blank and a table with technical parameters (thickness 57 mm, weight approx. 30 kg/m², sound insulation Rw 40 dB, thermal transmittance 1.0 W/m²K, climate 2a, fire EI30, smoke S200, burglary protection RC2). Additional information on customised blanks, maximum formats (e.g. EI30 single-leaf up to 3500×1660 mm), PEFC/FSC information and notes on instructions/technical data sheets.

Product data sheet for the UniStar 68 door leaf with fire protection. Thickness 67 mm, weight approx. 34 kg/m², sound insulation Rw 42 dB, thermal transmittance 0.9 W/m²K. Sound-insulating centre layer with hardboard top layer (7 mm) on both sides and finger-jointed hardwood edging. Suitable for increased sound requirements in offices, retirement homes, schools and hotels. Customised blanks up to 3000 x 1500 mm (one-piece); max. Size EI30: 1-leaf 3500 x 2100 mm, 2-leaf 3500 x 2640 mm. PEFC standard; FSC on request. Instructions and technical data sheets must be observed.

Product data sheet for the UniStar Alu 48 door leaf from ARBONIA. Door leaf with sound-insulating middle layer, hardboard top layer on both sides and aluminium sheet intermediate layer as well as finger-jointed hardwood inserts. Technical characteristics: Thickness 48.6 mm, weight approx. 29 kg/m², sound insulation Rw 40 dB, thermal transmittance 1.2 W/m²K, climate 3a/2b/2c, fire EI30, smoke S200, burglary protection RC2; PEFC certified (FSC on request). Max. Blank sizes up to 2750×1450 mm (one-piece), max. EI30: 1-leaf 2640×1400 mm, 2-leaf 2640×2300 mm. Notes: Cut-outs only possible at the factory; instructions and technical data sheets must be observed. Date: 28/05/2025.

Technical data sheet for the UniStar Alu 58 door leaf with fire protection from Arbonia. Contains characteristic values and performance data (thickness 58.6 mm, weight approx. 33 kg/m², sound insulation Rw 40 dB, thermal transmittance 1.0 W/m²K, climate 3a/2b/2c, fire EI30, smoke S200, burglary protection RC2), material information (hardwood, PEFC, MinEco), maximum dimensions (customised blanks up to 2750×1450 mm; EI30: 1-leaf 3500×1660 mm, 2-leaf 3100×2640 mm) as well as information on processing and references to instructions/technical data sheets. Suitable for room closures with increased climate and sound requirements (e.g. offices, retirement homes, schools, hotels). Date: 28/05/2025.

Technical data sheet for the UniStar Alu 68 door leaf with fire protection. Contains characteristic values and properties such as thickness 68.6 mm, weight approx. 37 kg/m², sound insulation Rw 42 dB, thermal transmittance 0.9 W/m²K, climate 3a/3b/2c, fire resistance EI30, smoke class S200 and burglary protection RC2. Information on material structure (hardwood and aluminium sheet layers), PEFC/FSC notice, maximum blank and EI30 dimensions as well as information on cut-outs and processing. Date: 28/05/2025.

Product data sheet for the ARBONIA UniStar Alu RC 58 door leaf series, containing technical characteristics such as thickness 57.8 mm, weight approx. 37 kg/m², sound insulation Rw 40 dB, thermal transmittance 1.0 W/m²K, fire protection EI30, smoke protection S200 and burglary protection RC3. Described are the structure (sound-insulating middle layer, hardboard top layer on both sides with aluminium sheet interlayer, finger-jointed hardwood inserts), suitability for offices, retirement homes, schools and hotels as well as possible maximum sizes (EI30/RC3) and information on PEFC/FSC and factory offcuts. Date: 28/05/2025.

Product sheet for the UniStar Alu RC 68 door leaf from ARBONIA. Door leaf with sound-insulating middle layer, hardboard top layer on both sides, aluminium sheet intermediate layer and finger-jointed hardwood inserts. Suitable for room closures with increased burglary, climate and sound requirements (e.g. offices, retirement homes, schools, hotels). Important characteristic values: Thickness 68.6 mm, weight approx. 38 kg/m², sound insulation Rw 42 dB, thermal transmittance 0.9 W/m²K, climate 3a/3b/3c, fire EI30, smoke S200, burglary RC3. Max. Dimensions EI30 up to 3500×2640 mm (2-leaf), RC3 up to 3100×2530 mm (2-leaf). PEFC standard (FSC on request). Status: 28.05.2025. Notes: Observe instructions and technical data sheets; cut-outs only possible ex works.

Product data sheet from Arbonia for the UniStar Top 48 door leaf with fire protection. Contains product image and technical data: thickness 47 mm, weight approx. 26 kg/m², sound insulation Rw 40 dB, thermal transmittance 1.2 W/m²K, climate 2a, fire protection EI30, smoke S200, burglary protection RC2. Material and construction information (sound-absorbing centre layer, laminated wood reinforcement, 7 mm hardboard top layer, hardwood glued-in edge), maximum blank sizes (up to 3000×1500 mm in one piece, max. EI30 dimensions shown), information on PEFC/FSC and processing instructions. Date: 28/05/2025.

Technical data sheet for the UniStar Top 58 door leaf from Arbonia. Contains product description, application examples (offices, retirement homes, schools, hotels) and characteristic values: thickness 57 mm, weight approx. 30 kg/m², sound insulation Rw 40 dB, thermal transmittance 1.0 W/m²K, climate 2a/2b, fire protection EI30, smoke S200, burglary protection RC2. Information on material (hardwood covering, PEFC; FSC on request), maximum finished dimensions, information on sound insulation blanks and processing/assembly instructions. Date: 28/05/2025.

Arbonia Imagemagazin: Premium doors, shower enclosures & dividing walls. Innovative space solutions for architecture, design & sustainability.

Arbonia sales team Switzerland: Personal consultants & technical expertise for doors, showers & dividing walls. Proximity to the client for sustainable solutions.

Arbonia ACRILEA: Acrylic glass surfaces with inlays - durable, scratch-resistant, UV-resistant. Creative designs for doors, furniture & room concepts.

Brochure from Arbonia on smart refurbishment solutions for residential entrance doors. It presents four tried-and-tested variants for retrofitting or replacing frames and door leaves, technical optimisations, threshold solutions and recommended components and products.
